MDMCP (12 SQ FT)

Nominal Impedance (ea)

2-Ohm
Internally wired to create a 2-Ohm amplifier load

Power Handling (Watts RMS)

500 Watts RMS
1000 Watts Max

Enclosure Material

5/8" MDF (Medium Density Fiberboard)

Woofer Quantity

2

Woofer Series

Punch P1 (P1S4-12)

Dimensions
Box (H x W x D)
Wedge (H x W x D1 x D2)

15.125" x 33.875" x 15.75"
(38.4cm x 86cm x 40cm)

Speaker Connector

Up to 10 AWG compression terminals

Enclosure Type

Vented

Woofer Size

12"

CEA-2031 Compliant

Shipping Weight

70.9 Lbs. (32.15 kg)

The most convenient way to get low frequency bass in your system is to drop-in a Punch Loaded enclosure. We're not talking junk in the trunk, we're talking the same genuine Punch woofers available separately. Punch Loaded enclosures are constructed with durable 5/8" MDF and tuned by our computer aided design software. P1 Loaded Enclosures feature similar tonal performance as P2/P3 models, but are easier to move in-n-out of vehicles due to their lighter weight.

FEATURES AT A GLANCE

• Constructed with 5/8" MDF
• Proprietary high-flow, low-noise port
• High current binding posts
