BE2000.1D

• MODEL 2000W High Output MONOBLOCK Amplifier
• Up to 1500 W X 1 RMS @ 1 ohm
• Up to 750 W X 1 RMS @ 2 ohm
• Up to 375 W X 1 RMS @ 4 ohm
• Monoblock, Class D, MOSFET Power Supply
• High and Low Level Inputs,
• Fixed High Pass Crossover, Variable Low Pass Crossover, Variable Bass Boost and Variable Subsonic Filter
• Include Remote Subwoofer Control
• Illuminated End Panel Strips 5 Years Elite Warranty
• Dimensions: 8.19" L x 1.69" W x 4.53" H

• Amp Topology    Monoblock, Class D
• Power Supply Type    MOSFET Power Supply
• Total Power Output    2000 Watts
• Peak Power @ 1 Ω    2000 Watts x
• Peak Power @ 2 Ω    1000 Watts x
• Peak Power @ 4 Ω    500 Watts x
• RMS Power @ 1 Ω    1500 Watts x
• RMS Power @ 2 Ω    750 Watts x
• RMS Power @ 4 Ω    375 Watts x
• Speaker Impedance    1 to 8 Ω
• T.H.D. (Total Harmonic Distortion)    0.01 %
• Frequency Response    9 Hz to " " ±1 dB
• Connections, Controls, and Processing    RCA Inputs    2 Channel
• High Level Inputs
• Low Pass Filter    50 Hz to Hz
• High-Pass Filter    Fixed " " Hz " " Hz
• Subsonic Filter    15 Hz to Hz
• Bass Boost    Variable " " " " " " dB
• Subwoofer Level Control
• Input Sensitivity Switch
• Thermal/Overload/Short Protection
• Measurement    Length    8.19 "
• Width    1.69 "

USER MANUAL
