TSB920

Total Power
(Sum of Rated Power)

600 Watts RMS

Signal Input

Low Level: 2 RCA Pair

Tone Controls

0dB to +18dB @ 45Hz

Bridgeable

Yes

Rated Power
(RMS Continuous Power)

100 Watts x 4 @ 4-Ohm
150 Watts x 4 @ 2-Ohm
300 Watts x 2 @ 4-Ohm Bridged

Crossover Controls

Front Channels: Variable 50Hz - 500Hz @ 12dB/octave
Rear Channels: Variable 50Hz - 500Hz @ 12dB/octave

Signal Output

Low Level: 1 RCA Pair

Power Input Connector

Block

Power Wire Gauge

4 AWG

Remote Controls

n/a

Speaker Output Connector

Block

Speaker Output Connector

Block

Heat Sink Type

Cast Aluminum

Frequency Response

20Hz to 20kHz +/-1dB

Dimensions (H x W x D)

1.97" x 6.77" x 11.06"
(5cm x 17.20cm x 28.10cm)

Circuit Topology Class

Full-Range Class D

Shipping Weight

7.038 Lbs.
(3.19 Kg.)

Efficiency (average)

80% @ 4-Ohm
75% @ 2-Ohm

Speaker Wire Gauge

12 AWG

Number of Channels

4

Cooling

Convection

Dynamic Power
(PVC/PowerCube®)

129 Watts x 4 @ 4-Ohm
220 Watts x 4 @ 2-Ohm
420 Watts x 2 @ 4-Ohm Bridged

CEA-2006 Compliant

CEA-2006 Power Rating
100W x 4 @ 4Ω
≤1.0% THD+N

The Prime M600-4D amplifier is a 600 Watt 4-channel high efficiency Class-D amplifier specifically designed for Marine and Powersport applications. The amplifier features a Marine grade PC Board, and the Class-D circuit topology is so efficient, it consumes much less current from your charging system over traditional Class-A/B amplifiers.

FEATURES AT A GLANCE

• 12dB/octave Butterworth crossover
• Top mounted controls
• Cast aluminum heatsink
• 4 Gauge power/ground connectors
• 2/4 channel input switch
• Marine grade 2-part epoxy coated PCB
• Tri-stage protection covers thermal, over-current and short circuits.
• On-board Punch EQ with +18dB boost @ 45Hz
