P500-12P

• hatchback-style powered ported enclosure with 12" sub
• Class D amplifier (500 watts RMS)
• 5/8" MDF enclosure with heat-activated vinyl finish
• remote bass-level control included
• quick disconnect connectors for easy removal
• intelligent auto turn on/off function
• separate low-level and speaker-level inputs
• variable low-pass crossover (50-200 Hz, 12 dB/octave)
• variable phase control (0° to 180°)
• variable bass boost
• frequency response: 20-200 Hz
• requires 8-gauge wiring kit (sold separately)
• fuses: 2 x 15A ATO
• dimensions: 26"W x 15"H x 11-1/2"D1 x 7-3/4"D2
• warranty: 1 year
• 60-day returns
• MFR # P500-12P

• Enclosure Type    Ported
• Finish Material    Vinyl
• Grille    Metal-mesh
• Connector Type    Removable terminal block
• Quick-disconnect Plug    Yes
• Bi-amp Inputs    No
• Woofer Size (inches)    12
• Woofer Material    N/A
• Passive Radiator    ---
• Width    26"
• Height    15"
• Depth    11-1/2"
• Parts Warranty    1 Year
• Labor Warranty    1 Year

Specifications

• Frequency Response    20-200 Hz
• Amplifier Power (RMS)    500 watts
• Maximum Wattage    ---
• Sensitivity    ---
• Impedance    ---
• Second Voice Coil Impedance    ---
• Crossover Point    50-200 Hz

Rockford Fosgate P500-12P owner's manual
