DIAMOND
MICRO1V2
MICRO 1-Ch 500W X 1 @ 1O RMS
- 500W x 1CH @ 1Ω / 300W x 1CH @ 2Ω / 175W x 1CH @ 4Ω RMS Power Output
- Input Sensitivity: 0.2-10 Volt
- Crossover Filter : 40-400Hz (LPF), 24dB Per Octave Slope
- Frequency Response: 10-500Hz
- Selectable REM / VOX / DC Turn On Modes
- Dimensions: 7.89” x 4.0” x 1.46” / 200.5 x 103 x 37.2 mm
- Remote Bass Knob Included
- Disconnected RCA Input & Speaker Output Harness Kits Included
- Amplifier 1 Channel
- RMS Power Rating 500 W RMS
- RMS Power(2Ω) 300 W
- RMS Power (4Ω) 175 W
- RMS Bridge (mono 1Ω) 500 W
- RMS Bridge (mono 2Ω) 300 W
- RMS Bridge (mono 4Ω) 175 W
- Topology Full-Range Class D
- Power Supply Full PWM
- Power Supply (Threshold) 10.0VDC – 17.0VDC
- Idle Current (0.7A)
- Distortion - THD (1KHz@4Ω) 0.5%
- Distortion - S/N Ratio (A weight @ 1W) -85dBA
- Distortion - S/N Ratio (A weight @ FP) -101.1dBA
- Input Sensitivity Low 200mV – 10.0V
- Input Sensitivity High N/A
- Input Impedance - Low Input Level 20 KΩ
- Input Impedance - AUX Input Level 20 KΩ
- Output Impedance 0.011Ω
- Damping Factor (50Hz@4Ω) >250
- Bandwidth (-3dB) 10Hz-350Hz
- Crossover (-12 dB/ Oct) Variable High-Pass N/A
- Crossover (-12 dB/ Oct) Variable Low-Pass 40Hz-400Hz
- Crossover (-12 dB/ Oct) Variable Sub-Sonic 10Hz-55Hz
- FUSE Ratings - ATC 25A
- Dimension - Length x Width x Height - Inches(mm) 7.89″ x 4.0″ x 1.46″ (200.5 x 103 x 37.2 mm)
