ROCKFORD FOSGATE
M2-200X2
2 channel Element Ready amplifier
50x2 @ 4O, 100x2 @ 2O, 200x1@ 4O bridged
50x2 @ 4O, 100x2 @ 2O, 200x1@ 4O bridged
- UV stable powder coated cast aluminum heatsink
- Zinc Nickel-plated Marine grade brass connection terminals
- Element Ready™ design protects against outdoor exposure
- Optimized using AudioGraph PowerCube measurement tool
- C.L.E.A.N. input/output clip detection and indicator LEDs
- Conformal coated circuit board protects against dust and water
- Focused mass heat sink allows critical aluminum material to be located around hottest internal devices
- RCA pass-thru outputs
- Variable Infrasonic Filter
- Fully Adjustable 12 dB/octave High and Low pass Butterworth Crossovers
- Short Circuit & Over Current Protection
- Top Mounted Control Panel
- Integration with OEM and Aftermarket Radios
- Integrated Power and Speaker Terminals
- Balanced Differential Inputs eliminates noise picked up by signal cables
- Quality & Performance tested using proprietary RATS (Rockford Automated Testing System)
- Low Impedance Stability
- 2-Year Warranty
- Auto-Sense bypass switch for vehicles with RAP (Retained Accessory Power)
- CEA-2006 Compliant & CE Compliant
- "Auto-Sense" turn-on with remote out (high level in)
- Cta-2006 Compliant
- Number of Channels2
Total Power
- (Sum of Rated Power)200 Watts
Rated Power
- (RMS Continuous Power)50 Watts x 2 @ 4Ω
- 100 Watts x 2 @ 2Ω
- 200 Watts x 1 @ 4Ω Bridged/Mono
Dynamic Power
- (PVC/PowerCube®)60 Watts x 2 @ 4Ω
- 107 Watts x 2 @ 2Ω
- 215 Watts x 1 @ 4Ω Bridged/Mono
- BridgeableYes
- Frequency Response20 Hz - 20 kHz
- Input SensitivityLow-Level: 150 mV - 4 V
- High-Level: 450 mV - 12 V
- Circuit Topology ClassClass D
- Efficiency (average)
- Total Harmonic Distortion (THD+Noise)4Ω: <1.0%
- 2Ω: <1.0%
- Signal InputLow-Level: 2 RCA
- High-Level: 4-Pin Molex
- Signal OutputLow-Level: 2 RCA
- (Pass-THru active with RCA or Hi-Level input)
- Tone ControlsNo
- Crossover ControlsHigh-Pass:
- 50 Hz - 250 Hz @ 12dB/Octave Butterworth
- Low-Pass:
- 50 Hz - 250 Hz @ 12dB/Octave Butterworth
- All-Pass: Yes
- Remote ControlsNo
- Visual IndicatorsPower/Protect
- C.L.E.A.N. In
- C.L.E.A.N. Out
- Power Wire Gauge4 AWG
- Power Input ConnectorCompression Terminal Block
- Speaker Wire Gauge8 AWG
- Speaker Output ConnectorCompression Terminal Block
- CoolingConvection
- Heatsink
- Operating Voltage9 - 16 VDC
- Recommended Fuse
- (not included)30 A
- Average Current Draw (13.8V Music)
- Max. Current Draw (13.8V Sinewave)18 A
- Suggested Alternator
Included In The Box
- Dimensions (H x W x D)1.9" x 6.8" x 8.1"
- (4.9 cm x 17.3 cm x 20.5 cm)
- Shipping Weight
