DIAMOND
HXM65
6.5" Marine Coaxial With 25mm Titanium Dome Tweeter (80W RMS / 400 PEAK) White & Black Grills Included
- 80W RMS
- Mounting Diameter: 5.27 inches / 134mm
- Mounting Depth: 2.18 inches / 55.5mm
- Over-All Diameter: 6.89" / 175mm
- Speaker Size - 6.5”
- Nominal Diameter (inch/mm) - 6.5" (165mm)
- Description -2-Way
- Nominal Impedance (ohms)- 4Ω
- RMS Power Rating -80W RMS
- Frequency Response - 45-23kHz
- Voice Coil Diameter (inch/mm) - 1.4" (35.55mm)
- Power Handling (RMS/Peak) -80/400
- Qts -0.783
- Fs-Free Air Resonance (Hz) - 75
- Vas (Liter) -0.159 (4.5)
- Xmax - Inch(mm) -0.16" (4mm)
- Sensitivity (1W/1M) -90.5dB
- Sensitivity (2.83V/1M) -93.5dB
- Mounting Diameter (inch/mm) -5.27" (134mm)
- Mounting Depth - 2.18″ (55.4mm)
- Tweeter- 25mm Titanium Dome
- Grille - Yes
HXMSPKR-MANUAL-Compressed (13.52 MB)
