DMH-WC6600NEX

Pioneer's NEX or Networked Entertainment eXperience line of receivers features an innovative and powerful new user interface that is responsive and highly customizable. The NEX models are designed especially for today's smartphone driven lifestyle.

Availability of non-Pioneer content and services, including apps and connectivity, may change without notice due to changes in operating systems, firmware, or app versions; changes to, restrictions on or discontinuation of the service or service plans; non-Pioneer hardware changes; or other events.

STANDARDS

• CTA-2006Yes

• Hi-Res CertifiedYes

PERFORMANCE

• Continuous Power Output22 W x 4-Channel

• Max Power Output50 W x 4-ch 4 ohm / 50 W x 2-ch 4 ohm 70 W X 1-ch (subwoofer) 2 Ohm

• RCA Preamp Outputs6-Channel

• RCA Pre-out4V

• RMS Power Output (CTA-2006)14 W RMS x 4-ch 4 ohm

DISPLAY

• Back LightLED

• Brightness ControlYes

• Color Customization5 display colors, 112 key colors

• Device (Non-DIN/Modular Unit)Modular, Non-DIN

• DimmerAutomatic with vehicle illumination, Timer Controlled, Manual

• Display Off ModeYes

• Home Screen CustomizationYes

• Monitor MechanismFixed

• ResolutionHD (1280 x 720)

• Screen Size/Aspect Ratio9"/16:9

• Touch ScreenCapacitive

BLUETOOTH

• Advanced Audio Distribution Profile (A2DP)Yes

• AVRCP1.6

• Built-in Bluetooth®Yes

• Dual Phone ConnectionYes

• Hands-FreeYes

• Microphone IncludedIncluded

• Secure Simple Pairing (SSP)Yes

• Serial Port Profile (SPP)Yes

TUNER

• Best Station MemoryYes

• HD Radio™Built In, Aritist experience, Multicasting

• Hybrid RadioYes

• Local Seek tuningYes

• Presets18 FM, 6 AM

• RDSYes

• SiriusXM-Ready™ (Tuner Sold Separately)Yes

INTEGRATION

• Amazon AlexaBuilt In

• Android Auto™Wireless Connection or Wired USB Connection

• Apple® CarPlayWireless Connection or Wired USB Connection

• Gracenote SportsYes

• Mobile Operating SystemAndroid / Apple iOS

• Music Playback (MTP)Yes

• Pandora®With Apple CarPlay or Android Auto

• Pioneer App CompatibilityCarAVAssist Android, CarAVAssist iPhone

• Siri® Eyes Free (VR) (Internet Required)iPhone Only

• SpotifyWith Apple CarPlay or Android Auto

• Voice ControlYes

• WiFiTethering, WiFi Hotspot

DIGITAL MEDIA PLAYBACK

• Audio Playback via USBMP3 Audio Playback / WMA Audio Playback / WAV Audio Playback (Hi-Res) / AAC Audio Playback / FLAC Audio / Playback (Hi-Res) / DSD Audio Playback (Hi-Res)

• Audio Video Playback via USB.avi / .mpg/mpeg / .divx / .mp4 / .3gp / .mkv / .flv / .wmv/.asf / .m4v / H.263 / H.264 / .ts/.m2ts/.mts

• Image Display via USBBMP / JPEG / PNG

AUDIO

• Bass BoostYes

• Built-in AmplifierMOSFET 50 W x 4

• Crossover Network ModeHPF/Band Pass/LPF

• Crossover Standard ModeHPF/LPF

• Customizable Graphic Equalizer13 Band

• DA Converter24 Bit

• Digital Signal ProcessorBuilt In

• Dynamic Bass EnhancerOff/Low/High

• Easy EQ (EEQ) Preset EqualizerYes

• Listening Position SelectorYes

• LoudnessHigh/Mid/Low/Off

• Speaker Output4-ch

• Spectrum AnalyzerYes

• Subwoofer ControlYes

• Time AlignmentManual

EXPANDABILITY

• OEM IntegrationiDatalink® Maestro™ - RR, iDatalink® Maestro™ - RR2, Metra Axxess

• OTA Update CompatibleYes

• Parking Assist LinesYes

• RCA Video OutputYes

• USBRear, Type-C (5 V, 3.0 Amp)

• USB Direct Control for iPhone®5s and newer

INPUTS

• Input 1Backup Camera Dedicated

• Input 2AUX (Minijack)

• Input 3A/V or 2nd Camera

• Input 4HDMI Micro (Type D)

GENERAL

• Detachable Face SecurityFixed

• Multi-Language DisplayEnglish, French, Spanish Portuguese, Chinese (Simplified)

• GPS AntennaYes

• Remote ControlIncluded

• Steering Wheel Control Ready (Adapter Sold Separately)Yes
