CP212-W0V3

Overview: The JL Audio slot-ported BassWedge subwoofer enclosure is designed around two of JL Audio's 12" W0v3-4 (4Ω) subwoofers. Aggressive tuning delivers powerful bass without the need for a huge amplifier. The MDF enclosure is covered with gray carpet and has JL AUDIO logos embroidered across the top and front. The enclosure design offers a variety of installation options: forward, rear or down firing. The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofer; the port mouth is flared to minimize air-flow noises.

Speaker Terminal: The enclosure uses one pair of nickel-plated, high current spring posts. The posts are located on the left side of the box and will accept pin connectors, single or dual banana plugs, or bare wire up to 10 gauge.

W0v3 Woofer Features:

• Dynamic Motor Analysis (DMA): DMA is JL Audio's proprietary method of improving dynamic motor behavior. As a result of DMA optimization, the 12W0v3-4 motor displays linear force over a long excursion range, and also maintains a stable fixed magnetic field in the gap over a wide power range. The result is a reduced distortion, faithfully reproduced transients, and tight, clean, articulate bass.
• Elevated Frame Cooling: The elevated frame design of the 12W0v3-4 delivers cool air through slots directly above the top plate to the voice coil. This not only enhances power handling, but also sound quality by minimizing dynamic parameter shifts and power compression.
• Rear Gasket: The woofer has a rear gasket to provide an optimal seal when installing into the enclosure.
• Long Excursion: The subwoofer has an Xmax of 11.4mm, giving you louder bass with less distortion.

Optional Grille: The optional SGRU-12 grilles (item number 136SGR1231, sold separately and individually) can be added to protect the woofer cones.

Dimensions: The CP212-W0v3 enclosure isn't symmetrical; it's approximately 31-5/8" wide, 15-1/4" tall at its tallest point (toward the front), 12-7/8" tall at its shorted point (toward the back), 20-5/8" deep at the base, and 16-5/8" deep at the top.

• General
• Woofer Size (inches)    12
• Speakers Per Box    2
• Woofer Material    Polypropylene
• Enclosure Type    Ported
• Color    Gray
• Pieces in System    1
• Width (inches)    31-5/8
• Height (inches)    15-1/4
• Depth (inches)    20-5/8
• Connector Type    Spring post
• Frequency Response    22-250 Hz
• Power Range (Watts RMS)    600
• Maximum Wattage    1200
• Sensitivity    86 dB
• Impedance    2 ohms
