51KM614FL

Marine-Ready: The Kicker KM series marine coaxial speakers are engineered to meet or exceed ASTM B117 Salt Fog (200 hour test) and ASTM G154 Accelerated UV (400 hour test) industry standards. The speakers feature sealed motors, cones, and locking wire terminal covers.

Thin-Mount Grille: The KM614FL marine speakers come with a thin-mount grille design for a non-intrusive installation and more subtle look. You can choose between a removable white or silver grille.

LEDs: There are multi colored LEDs behind the tweeter casing, to create a glow on the woofer cone. Depending on what combination of the three LED wires is connected, they can light red, green, blue, lime green, magenta, aquamarine, or blue-white. A wireless remote (item number 20641KMLC, sold separately) is also available to control the backlighting. A 12 volt power supply is needed to turn the LEDs on.

Terminal Cover: The speakers feature splash and spray resistant, locking terminal covers. These covers have water-resistant gaskets to prevent terminal corrosion and electrical shorting.

• 2-way 6-1/2" marine speakers (pair)
• variable-color RGB LED backlight
• package includes white and silver grilles
• slim chassis is ideal for marine use
• UV-treated polypropylene woofer cone with santoprene rubber surround
• 1/2" PEI dome tweeter
• UV-resistant polymer basket
• power handling: 60 watts RMS (130 watts peak power)
• frequency response: 35-21,000 Hz
• sensitivity: 90 dB
• impedance: 4 ohms
• mounting depth: 2-15/16"
